Unmanned Weighbridge
System

Download Unmanned Weighbridge System Brochure

What is Unmanned Weighing?

Weighing automation is the future of weighing operations. Industries across the globe require weighing to measure materials across all the phases of the supply chain, which makes human reliance and dependency very dangerous. Endel Digital Solutions is here to solve all the problems created by the traditional weighment systems.

Manpower costs

Sites that run 24/7 operations require multiple weighbridge operators, the wages of the operators and the supervisors are a significant cost to the organization

Delay in operations

Manpower-dependent operations always experience delays due to unforeseen circumstances.

Errors in data capturing

Intentional or unintentional errors in the data capturing can cause significant discrepancies and issues moving ahead in the supply chain operations.

Difficulty in supervision and reporting

As all the data is manually captured, there are high chances of errors, which are difficult to fix at a later stage, and manually prepared reports are time consuming and inaccurate due to the inaccurate data

Why should you invest in upgrading your weighbridge?

How does an unmanned system works?

01 Phase

Authorization

This is a fail-safe method to ensure that only authorized trucks are entering the premises. Only after the data is captured from the RFID or the ANPR system, does the boom barrier open, and the truck enters the weighbridge.

02 Phase

Positioning

Mispositioned trucks do not give accurate weighment, this would cause the wrong data to be stored, and affect the rest of the supply chain processes. Our Unmanned System utilized position sensors to ensure that every single truck weighment is accurate.

03 Phase

Weighment

CCTV/IP cameras are present to enhance security and safety. The system automatically captures various images of the truck, and stores it along with the weighment data. After all the data is stored on the system, the barriers open and the truck is allowed to leave.

04 Phase

Transaction completion

After the gross/tare weights are measured, automated text alerts/email alerts are shared to all relevant personnel. All the information, including the photos of the truck, are ready to view on all platforms, this includes the software, the cloud server, or the ERP platform.

Unmanned Weighbridge System - Automated Weighbridge Management System Software
01

Phase One

  • Authorization: RFID/UHF card reader authorizes the vehicle
  • Opening Barricade: Barricade automatically opens after authorization
Unmanned Weighbridge Software
02

Phase Two

  • Sending a Signal: As soon as the truck reaches the center of the weighbridge, the position sensor sends a signal for measuring weighment.
  • Capturing Weighment: The weighing unit load cells in unattended weighbridge system capture weighment after getting the signal.
  • Truck Identification: IP camera sends the truck image to the weighbridge software.
  • Weighment Information: A jumbo display connected to weighing bridge software shows weighment information to the truck driver.
  • Weighing Information Processing: The indicator at the control room processes the information and sends it to the weighing software.
Unmanned Weighbridge System - Automated Weighbridge Management System Software
03

Phase Three

  • Unloading the Vehicle: Again, the jumbo display presents the weighment information to a truck driver on returning.

How Does A Weighbridge Work Without Manpower?

The entire unmanned weighbridge system runs based on automation. The functions that are operated by a man are executed automatically through the automated weighbridge system features. The step by step process is as below:

Our Deliverables

What You Can Gain from Unmanned Weighbridge Software?

shape 3 1 1 shape 4 1 1 shape 6 1 1

Smooth Functioning

Enhancing the functions with automation

shape 3 1 1 shape 4 1 1 shape 6 1 1

Well Ordered Process

Removing the possibility of missing out on any crucial step

shape 3 1 1 shape 4 1 1 shape 6 1 1

Increased Potential

Boosting opportunities by elevating efficiency

What You Can Gain from Unmanned Weighbridge Software?
What You Can Gain from Unmanned Weighbridge Software?

Main Components of Unmanned Weighing System

Weighbridge System Software

Weighbridge System Software

Modifies the weighbridge working principle to meet your specific requirements.

Automated Identification System on Truck Weighbridge Management Software

RFID reader

To prevent misemployment of weighbridge functions by an unauthorized person.

Automated Weighbridge System Software

Automated Weighbridge System

Automates the functionality of the system eliminating the involvement of men.
Weighbridge Management System

Weighbridge Management System

Completely innovative weighing system facilitates flexibility & higher productivity.

Weighbridge Machine Software

Automated Weighing Software

To store, manage & track the data to ensure an accurate overview.

CCTV Video Surveillance Weighing Software

CCTV Video Surveillance

To keep an eye, especially on truck drivers and vehicles that enter & exit.

Traffic Lights Weighbridge Machine Software

Traffic Lights

To communicate with truck drivers about when to enter or exit the weighing bridge.

Barrier Gates & Security - Weighbridge Management System

Barrier Gates & Security

Manages traffic on the weighing bridge by automatically opening and closing the gate based on signals.

Digital Displays Truck Weighbridge Software

Digital Displays

To read the information of weighment to the truck driver integrated with unmanned weighbridge systems.
bg 3
System Benefits

The Whys & Wherefores of Unmanned Weighing

Unmanned Weighbridge System

How to prevent theft
at your weighbridge?

From our years of experience and working with clients across numerous industries, We have gained a deep understanding of the problems that our clients have regularly faced, in terms of theft. Traditional weighbridge systems allow certain weighbridge malpractices to go unnoticed. One of the biggest malpractices that causes huge losses to any organization is theft. The amount of Weighment thefts occurring globally, have significantly risen over the years and this has become a major concern for all companies that utilize weighbridges at their facilities, big and small organizations are falling victim to these malpractices which result in huge losses

There are many other ways in which a weighbridge can be cheated, and theft may occur, we will be highlighting some of these ways and how WeighMAST solves these problems, and reduces the chance of theft.

Hardware Components

Control Panel
RFID Reader /
ANPR Camera

Position sensors

IP Camera

Barricades

Traffic lights

Jumbo display

Announcement
system

Software Components

WeighMAST - Weighbridge data management software

This enterprise-focused weighbridge management software is suitable for any organization which requires accuracy, visibility, and traceability in its operations. WeighMAST allows companies to automate their entire weighbridge operation to achieve the same.
